How to Replace A Pull Cord on A Push Lawn Mower?

18 minutes read

To replace a pull cord on a push lawn mower, you will need to follow these steps:

  1. Safety first: Before starting any work on your lawn mower, make sure it is turned off and remove the spark plug wire to prevent accidental starting.
  2. Remove the old cord: Locate the recoil starter assembly on the mower (usually located on the top of the engine). Unscrew and remove any screws or bolts securing the assembly cover. Once the cover is off, you will see the old pull cord coiled up inside it. Carefully unwind and remove the old cord.
  3. Prepare the new cord: Purchase a replacement pull cord from a hardware store or online, ensuring it is the correct length and thickness for your mower. Cut the new cord to the required length, leaving some extra length to work with.
  4. Attach the new cord: Feed one end of the new cord through the hole in the recoil starter assembly cover from the inside. Tie a knot at the end of the cord to prevent it from coming out. Pull the cord through until the knot is securely seated against the inside of the cover.
  5. Wind the recoil spring: On the inside of the recoil starter assembly, you will find a small pulley with a recoil spring attached. Hold the pulley to prevent it from spinning and wind up the recoil spring in the direction specified on the assembly.
  6. Attach the cord to the pulley: Once the spring is wound, carefully thread the free end of the cord through the eyelet or notch on the pulley. Tie a knot at the end of the cord, ensuring it holds securely.
  7. Reassemble the recoil starter assembly: Slowly release the tension on the pulley, allowing the spring to draw the cord onto it. Gently guide the cord as it winds onto the pulley, making sure it stays in the track. Once the cord is fully wound, reattach the recoil starter assembly cover and secure it with the screws or bolts.
  8. Test the new cord: Give the cord a few gentle pulls to ensure it operates smoothly and retracts properly. If it does not, you may need to repeat the process and adjust the tension on the recoil spring.


Remember to always refer to the manufacturer's instructions for specific guidance on your lawn mower model.

Best Push Lawn Mowers of 2024

1
YARDMAX 21 in. 170cc 2-in-1 Gas Walk Behind Push Lawn Mower with High Rear Wheels

Rating is 5 out of 5

YARDMAX 21 in. 170cc 2-in-1 Gas Walk Behind Push Lawn Mower with High Rear Wheels

  • Single-lever deck adjustment for quickly setting your mow height
  • MAXFlow Deck Technology – volute spiral deck design for better airflow and mulching
  • Heavy-duty, 16-gauge stamped steel deck
  • Durable, one-piece seamless steel deck reduces vibration
  • Seven cutting heights from 1.25″ to 3.75″
  • Double-ball-bearing wheels for easy, smooth mowing with less pushing effort
  • Adjustable, durable 3-position handle height
  • Folds for space-saving storage
  • 7 in. front and 11 in. rear wheels for stability and control
2
PowerSmart Gas Lawn Mower 21 Inch 2-in-1 with 144CC 4-Stroke Engine, Push Mower Gas Powered DB2321CR

Rating is 4.9 out of 5

PowerSmart Gas Lawn Mower 21 Inch 2-in-1 with 144CC 4-Stroke Engine, Push Mower Gas Powered DB2321CR

  • 144CC OHV ENGINE: reliable engine, recoil starter for easy start, forced air cooling system continuously deliver unbeatable grass cutting effect.
  • 21 INCH CUTTING DECK: patented cutting system with 21 inch cutting deck, wider mowing path helps you trim sizable yard fast.
  • 2-IN-1 PUSH MOWER: side-discharge easily pass thick grasses for quickest mowing, mulching lawn mower minces grass into super-fine bits for recycle.
  • GRASS HEIGHT ADJUSTABLE: 6 positions for adjust cutting height from 1.5" to 3.9", suitable for all kinds of grasses.
3
BILT HARD Gas Lawn Mower 20 inch, 2 in 1 170cc 4-Stroke OHV Engine Cordless Lawnmower, 8 Adjustable Cutting Heights Push Mowers for Lawn, Yard and Garden

Rating is 4.8 out of 5

BILT HARD Gas Lawn Mower 20 inch, 2 in 1 170cc 4-Stroke OHV Engine Cordless Lawnmower, 8 Adjustable Cutting Heights Push Mowers for Lawn, Yard and Garden

  • Auto Choke Engine - 170cc 4-stroke OHV engine, 6.5 ft.lb torque, 20 inch cutting deck.
  • Cutting Height - 8-position single lever four-wheel synchronized height adjustment from 1.2" to 3.2".
  • Mowing Convenience - 7" rear/6“ front double ball-bearing wheels achieve smooth movement, comfortable foam-wrapped angled grip eliminates grasp fatigue.
  • Durable Cutting Deck: 20" cutting deck and specialized blade delivering a clean, even cut. Enjoy years of high efficient mowing with superior cutting quality
4
Greenworks 40V 16" Cordless (Push) Lawn Mower (75+ Compatible Tools), 4.0Ah Battery and Charger Included

Rating is 4.7 out of 5

Greenworks 40V 16" Cordless (Push) Lawn Mower (75+ Compatible Tools), 4.0Ah Battery and Charger Included

  • CORDLESS LAWN MOWER – Get more done, faster, with Greenworks electric lawn mowers. This 40v push lawn mower provides the power you need with up to 45 minutes of runtime on a fully charged 4.0Ah battery. The battery completely charges in 120 minutes.Brushless motor : No
  • LIGHTWEIGHT, EASY TO USE – A lightweight 16” cutting deck allows for easy maneuvering through small to medium yards (up to ½ acre) more efficiently. Easy push button start and lighter weight make it a great choice for your lawn.
  • VERSATILE – Battery powered lawn mower has a single lever 5-position height adjustment with a cutting height range from 1-1/4" to 3-3/8" for the best cut in all environments. The 2-in-1 feature offers versatile use with mulching and rear bagging options.
  • MAINTENANCE FREE – This walk behind lawn mower is virtually maintenance free, with no gas, no oil and no emissions. It starts instantly and is quiet but delivers gas-like power for your toughest projects.
5
Yard Machines 11A-02BT729 20-in Push Lawn Mower with 125cc Briggs & Stratton Gas Powered Engine, Black and Red

Rating is 4.6 out of 5

Yard Machines 11A-02BT729 20-in Push Lawn Mower with 125cc Briggs & Stratton Gas Powered Engine, Black and Red

  • A 125cc OHV Briggs & Stratton engine delivers reliable power to quickly tackle your yard
  • Push mower ideal for small yards with minimal obstacles
  • 20-in. deck with side discharge to efficiantly spread grass clippings
  • 7-in wheels provide reliable traction to navigate your yard
  • Choose from 3 cutting heights
6
BLACK+DECKER Electric Lawn Mower, 10-Amp, Corded (BEMW472BH)

Rating is 4.5 out of 5

BLACK+DECKER Electric Lawn Mower, 10-Amp, Corded (BEMW472BH)

  • Lightweight corded electric mower gasless 10 Amp 15 inch electric mower for powering through rough grass.Ideal for 1/8 acre.Voltage : 120 V. Product Application : Cleaning.
  • Comfort grip bike handlebar design reduces friction and enhances maneuverability for small lawns
  • Enhanced clipping collection winged blade yields 30% better clipping collection
  • Push button start no-hassle startup easy-to- use features
  • Adjustable cutting height 6 adjustable cutting heights ranging from 1 inch to 3 inch
7
CRAFTSMAN Gas Powered Lawn Mower, 21-inch Push Mower, 140cc (M105)

Rating is 4.4 out of 5

CRAFTSMAN Gas Powered Lawn Mower, 21-inch Push Mower, 140cc (M105)

  • POWERFUL ENGINE: 140cc BRIGGS & STRATTON engine with auto-choke
  • MOWING CONVENIENCE: 21 in., 3-in-1 convertible deck lets you side discharge, mulch, or rear bag grass clippings
  • CLIPPING COLLECTION: Rear bag collects grass clippings for easy cleanup or composting
  • HEIGHT ADJUSTMENT: Dual-lever, 6-position height adjustment makes it easy to change cutting heights from 1.25 in. to 3.75 in. high
  • COMFORT: Adjustable loop handle for comfort while mowing. MULCH KIT: Included to help put nutrients back into soil for a healthy lawn
8
BLACK+DECKER 3-in-1 String Trimmer/Edger & Lawn Mower, 6.5-Amp, 12-Inch, Corded (MTE912) (Power cord not included), Black/Red

Rating is 4.3 out of 5

BLACK+DECKER 3-in-1 String Trimmer/Edger & Lawn Mower, 6.5-Amp, 12-Inch, Corded (MTE912) (Power cord not included), Black/Red

  • 3N1 DESIGN – Electric mower easily converts to string trimmer and edger via a built-in foot pedal for versatile use.
  • 6.5 AMP MOTOR – Supplies the ideal amount of power when trimming grass, weeds, and overgrowth.
  • GEAR DRIVE TRANSMISSION – For tackling tougher, thicker grass without getting bogged down.
  • AFS AUTOMATIC FEED SPOOL – Continuously feeds trimmer line without bumping for seamless, uninterrupted trimming.
  • ADJUSTABLE MOWER DECK AND TRIMMER HANDLE – Lawn mower deck and string trimmer handle are adjustable for ideal grass- cutting height and added comfort.
  • CORDED – Corded design offers unlimited runtime for even the biggest jobs.
  • INCLUDES – (1)GH912 trimmer/edger, (1) MTD100 detachable mower deck, (1) AF-100 spool, (1) auxiliary handle, (1) guard.
  • Note: Item requires power cord. Power cord not included


How to maintain and clean the pull cord assembly for extended durability?

To maintain and clean the pull cord assembly for extended durability, you can follow these steps:

  1. Remove any debris: Start by inspecting the pull cord assembly and removing any dirt, dust, or debris that may have accumulated on or around the assembly.
  2. Lubricate the moving parts: Apply a small amount of lubricant (such as silicone spray or chain lubricant) to the moving parts of the pull cord assembly. This will help reduce friction and wear, ensuring smooth operation.
  3. Check and tighten screws or bolts: Inspect the screws or bolts that secure the pull cord assembly to the device it is attached to (e.g., lawnmower, generator). Make sure they are tightened securely to prevent any vibrations or looseness that may damage the assembly.
  4. Inspect the pull cord: Check the pull cord for any signs of wear, fraying, or tearing. If the cord is damaged, it should be replaced with a new one to ensure proper functioning and prevent accidents.
  5. Clean the cord and pulley: If there is any dirt or grime on the cord or pulley, wipe them down with a clean cloth or brush to remove it. You can also use a mild detergent if necessary, but make sure to rinse thoroughly and dry completely afterward.
  6. Protect the pull cord assembly: If the pull cord assembly is exposed to harsh weather conditions or extreme temperatures, consider covering it or providing additional protection to prevent damage and premature wear.


By following these steps regularly, you can maintain and clean the pull cord assembly to ensure extended durability and reliable operation.


How to test the tension of a new pull cord?

To test the tension of a new pull cord, you can follow these steps:

  1. Start by ensuring the equipment attached to the pull cord is in the disengaged or off position. This will help prevent any accidental starting during testing.
  2. Locate the pull cord handle and hold it firmly.
  3. Gently pull the cord outward until you feel resistance. This is often the recoil of the cord retracting.
  4. Slowly release the tension by letting the cord retract on its own back to its starting position.
  5. Repeat this pulling and releasing process several times, ensuring the cord retracts smoothly each time.
  6. Pay attention to the tension while pulling. The cord should give you a moderate resistance that feels consistent with other similar equipment you've used in the past.
  7. Observe any signs of fraying, weakness, or abnormal stretching in the cord during the tension testing process. If any issues are detected, it's best to replace the pull cord before using the equipment.
  8. After testing, engage the equipment and test its functionality to ensure everything is operating as intended.


Remember to always follow the manufacturer's instructions for your specific equipment, as some may have additional guidelines or recommendations for testing pull cord tension.


What is the role of the pull cord in the engine ignition process?

The pull cord, also known as a starter cord or recoil starter, is used to start small engines such as those found in lawn mowers, chainsaws, and generators. Its role in the engine ignition process is to initiate the firing of the engine by turning the crankshaft and generating the necessary momentum to ignite the fuel-air mixture.


When the pull cord is pulled forcefully, it rotates the engine's crankshaft, which compresses the fuel-air mixture in the combustion chamber. This compression increases the temperature and pressure of the mixture. As the cord is released, it rewinds, and the stored energy is transferred to turn the crankshaft rapidly. This rapid rotation creates a spark in the spark plug, which ignites the compressed fuel-air mixture, starting the engine.


The pull cord is typically connected to a starter mechanism that includes a pulley, a spring, and a recoil mechanism. When the cord is pulled, the spring is tensioned, and upon release, it rewinds the cord back onto the pulley, ready for the next pull.


Overall, the pull cord is vital to the engine ignition process as it provides the initial force needed to rotate the crankshaft, compress the fuel-air mixture, and initiate the combustion required for starting the engine.


How to buy the right replacement pull cord for a lawn mower?

To buy the right replacement pull cord for a lawn mower, follow these steps:

  1. Determine the specifications: Note down the specific make, model, and year of your lawn mower. Additionally, find out the engine size and type. This information will help you identify the exact replacement pull cord.
  2. Measure the cord length: Take the old pull cord off the mower and measure its length. Ensure the measurement is accurate as it will help you buy the correct size.
  3. Consider the cord material: Replacement pull cords are typically available in nylon or braided steel. Nylon cords are suitable for lighter-duty mowers, while braided steel cords are more durable and ideal for heavy-duty mowers.
  4. Examine the attachment mechanism: Observe how the pull cord is attached to the starter assembly. There are generally two types of attachment mechanisms - a knot or a plastic handle. Ensure that the replacement cord has the same attachment method as your old one.
  5. Find a reliable supplier: Visit a local lawn mower repair shop or home improvement store that specializes in outdoor power equipment. Bring the information you gathered about your lawn mower and the old pull cord to find the right replacement.
  6. Consult the store associate: Speak to someone knowledgeable about lawn mower parts at the store. Provide them with the make, model, and engine specifications of your lawn mower. They will guide you in selecting the appropriate replacement pull cord.
  7. Consider buying a universal pull cord: If you are unable to find an exact match for your lawn mower, consider purchasing a universal pull cord kit. These kits are designed to fit a wide range of models and come with multiple attachments, allowing you to adapt it to fit your mower.
  8. Purchase the replacement pull cord: Once you have identified the correct replacement, make the purchase. Check if the package includes any additional hardware, such as screws or washers, which may be needed during installation.
  9. Install the new pull cord: Follow the manufacturer's instructions for installation. If needed, consult online resources or guides for step-by-step instructions specific to your lawn mower make and model.


Remember, if you are uncomfortable or unsure about replacing the pull cord yourself, it is best to consult a professional or take your lawn mower to a repair shop for assistance.
